Powder Coating Automatic Gun AG01

Powder Coating Automatic Gun AG01 Price And Quantity

• Minimum Order Quantity 1

Powder Coating Automatic Gun AG01 Product Specifications

• Color White and Blue
• Coating Format Spray Application
• Coating Width Adjustable Spray Pattern
• Weight (kg) Approximately 600 g (Gun only)
• Power Source Electric
• Coating Type Electrostatic Powder Coating
• Coating Transfer Method Electrostatic Spray
• Feeding Type Powder Feed Hopper
• Coating Speed Up to 200 g/min
• Drive Type Manual/Automatic
• Dimension (L*W*H) 430 x 230 x 130 mm (Gun only)
• Power Consumption 40W-50W
• Voltage 220 V AC
• Machine Speed Adjustable by Controller
• Coating Material Thermoset & Thermoplastic Powder
• Power Requirement 40W (Gun only)
• Feature High Transfer Efficiency, Low Powder Consumption, Easy Operation
• Type Automatic
• Computerized No
• Coating Head Integral with Gun
• General Use Powder Coating of Metal Surfaces
• Control System Digital Microprocessor Controller
• Product Type Powder Coating Automatic Gun
• Material High Impact Engineered Plastic
• Registration Automatic Powder Flow Control
• Max. Coating Area Wide range as per part size (customizable)
• Automatic Yes

• Powder Flow Adjustment Available
• Trigger Type Solenoid/Manual
• Safety Features Over-voltage and Over-current Protection
• Nozzle Type Interchangeable round/flat
• Display Type Digital LED Indication on Controller
• Mounting Mode Robot/Static/Side Rail Mountable
• Max Output Voltage 100 kV (Adjustable)
• Air Pressure Required 5-6 bar
• Suitable Powders All types of polyester, epoxy, hybrid, primer powders
• Gun Technology Corona Charging
• Operating Temperature 5C to 50C
• Gun Cable Length 5 meters
