Product Description
1. Detachable gun body
2. Stable electrostatic output
3. Detachable gun stand with combined powder hose and cable
4. Flat nozzle with self-lubricating central electrode seat
5. Cable length 20 [m]
6. Powder hose, inner diameter: 11 [mm]
7. Current limit setting
8. Capable of spraying metallic powder without any additional components
9. Easy to clean and maintain
10. Design with quick color change
11. High powder charging effect
12. Stable Cloud.
Advanced Powder Coating TechnologyThe AG01 integrates corona charging with electrostatic spray technology, providing a uniform, high-quality finish on a wide range of metal surfaces. Its digital microprocessor controller allows precise adjustments, while built-in over-voltage and over-current protections ensure operator safety and reliable performance.
Versatile Use and Flexible MountingSuitable for a variety of powders-polyester, epoxy, hybrid, and primer-the AG01 supports both manual and automatic drive modes. It mounts easily on robots, static points, or side rails, enabling seamless incorporation into automated or standalone workflows.
User-Centric Design for EfficiencyEngineered from high-impact plastic, the AG01 is lightweight and comfortable to operate. The spray pattern and machine speed can be finely tuned via the controller, catering to parts of different sizes and shapes for customizable coating results with minimal powder waste.
FAQ's of Powder Coating Automatic Gun AG01:
Q: How is the Powder Coating Automatic Gun AG01 operated during the coating process?
A: Operation is facilitated through a digital microprocessor controller with a digital LED display. Users can adjust voltage, spray pattern, powder flow, and speed directly on the controller, ensuring precise application for different parts and surfaces.
Q: What materials and powders are compatible with the AG01 powder coating gun?
A: The AG01 is compatible with all types of polyester, epoxy, hybrid, and primer powders, along with other thermoset and thermoplastic coatings, making it suitable for a diverse array of industrial powder coating tasks.
Q: When should the air pressure and voltage settings be adjusted for optimal performance?
A: Air pressure (5-6 bar) and output voltage (up to 100 kV) should be set according to the powder type and part geometry. Adjust settings before starting the coating to ensure even coverage and high transfer efficiency while minimizing powder waste.
Q: Where can the AG01 powder coating gun be installed or mounted?
A: The gun can be mounted on robots, static frames, or side rails, adapting easily to both automated production lines and manual workstations, offering flexibility to meet varied operational requirements.
Q: What is the process for changing the spray pattern or nozzle type on the AG01?
A: The AG01 features interchangeable round and flat nozzles. To change the spray pattern, simply replace the nozzle as needed. The controller allows further adjustment, achieving the desired coating width and distribution for different workpieces.
Q: How does the AG01 ensure safety and operator protection during use?
A: Safety is assured through built-in over-voltage and over-current protections. The digital controller supervises electrical parameters, shutting down the system automatically if thresholds are exceeded, thereby preventing equipment damage and protecting users.
Q: What benefits does the Powder Coating Automatic Gun AG01 offer in terms of efficiency and user experience?
A: The AG01 delivers high transfer efficiency and low powder consumption, with easy operation via a clear digital interface. Its lightweight design reduces operator fatigue, and the customizable spray pattern supports coating a wide range of part sizes efficiently.
